The ATAC XC 10 is a favourite pedal of competitive riders because of its light weight and ergonomic design. The pedal features the lightness of a carbon body with the durability of a hollow steel axle, as well as tension adjustment to fit your needs. Freedom of movement lateral and angular for reduced injuries and muscle fatigue.

The pedal's self-cleaning design clears mud and debris each time you step in. The ATAC XC 10 offers easy and consistent engagement with tension adjustment to meet your pedal preference and needs. This pedal is a great option for XC, gravel, or cyclocross.

Specifications

• Axle Component: Hollow steel axle
• Bearings: Steel
• Body component: Carbon-filled
• Cleats: ATAC cleats
• Pedal stack height: 18.3mm
• Angular freedom: 5° to -5° with free cleats, 0° with fixed cleats
• Contact surface area: n/a
• Distance pedal spindle / crank arm: 54mm
• Lateral freedom: 2.5 mm or -2.5 mm
• Release angle: 10° with ATAC Easy cleats, 13 or 17° with ATAC cleats
• Tension: 3 different positions of the spring
• Threading: 9/16 - 20 inch
• Platform Size: n/a
• Colour (Pedal): Carbon
• Accessories: ATAC cleats
• Intended use: XC, CX, Gravel
• Power Measurement: Not Compatible
• Weight (per pedal): 140g

Features

• Easy clip in and pedal engagement.
• Light hollow steel axle and carbon body for light weight.
• Self-cleaning design to push out mud with step in.
• Tension adjustment.
• Cleats included with all pedal purchases.
• Model ID: PD-XC-10-C1
