Ohlins RXF36 M.2 Trail Air Fork - 27.5 Inch - 1 1/8th - 1.5 Inch Tapered - 15x110mm Boost - 180mm - 46mm - TTX18 Damper
No one knows suspension like Ćhlins, their proprietary technologies ā developed from multi-discipline know-how help you ride smoother, faster and push the boundaries of your MTB.
The all-new RXF36 M.2 fork takes the race-proven TTX 18 damping from the Ćhlins DH38 Race Fork and reworks it to provide optimal traction and control on trails and Enduro racecourses.
The TTX 18 cartridge kit features a trail-optimized 18mm piston for ultra-sensitive tracking over small bumps and the damping valve response and sensitivity greatly surpass the original RXF36 fork to provide unrivalled traction control and ultra-consistent performance ā no matter how tough the trail gets.
The damping adjustment range is set specifically for tough trails and enduro races with 15 clicks of low-speed compression and low-speed rebound. For the high-speed compression damping, you get 3 clicks plus a climb mode setting.
The retuned, twin-piston, three-chamber air-spring system allows you to completely dial in the level of progression ā from the initial movement, right through to bottom out.
Tyre clearance has also been improved. The chassis will take up to 29 x 2.8" as well as 27.5+ x 3.2". There are many technical improvements in the fork but Ohlins did not stop there, the design has also been updated and matches what you see on the racecourses.
Who's this item for: Trail and enduro riders who want a fork that offers a multitude of tuning options to dial in their ride perfectly.
Spring type: Twin-piston, three-chamber air spring.
Wheel size compatibility: 29", 27.5+
Fork offset: 44mm or 51mm
Axle to crown height: 580mm
Max tyre width: 29 x 2.8", 27.5+ x 3.2"
Suspension travel amount: 150-170mm
Compression damper style technologies / adjustments:
- 15-click low-speed compression damping
- 3-click high-speed compression damping
- Climb mode
Rebound damper technologies/adjustments:
- 15-click rebound damping
Travel adjustability: There are no external controls to adjust the length of travel. Will require air spring disassembly.
Stanchion diameter: 36mm
Axle size and style: 15 x 110 mm
Steerer tube standard: Tapered 28.6 - 38.1mm (1.5 - 1 1/8")
Lowers materials: Aluminium design, hard anodized.
Brake hose clamp/retention style: Hose clamp on the crown
Brake mount style: Post Mount.
Brake rotor compatibility: 180mm minimum
Weight: 2159g (Based on 160mm/29ā)
E-Bike Approved: Yes
